9F30246 Modine Replacement Motor 200-230V

• 1/15HP, 0.5-0.6 amps, 200-230V 60HZ; 1050 RPM
• Rotation = CW
• 5-5/8″ Diameter
• Shaft: 1/2″ x 3-1/4″
• Case Length 4″
• 4 studs-shaft end; 5-1/8″ O.C.
• 2 wire leads 36″
• One Year Warranty

Reference: 9F030246, K55HXRHT-1975, Replaces 9F10238, DA3G140N, DA3G140 (check amps & voltage)
