Description
- HP: 1/10
- Voltage: 115
- RPM: 3275
- AMPs: 0.8
- Phase: 1
- Rotation: Reversible
- Frame: 3.3
- Enclosure: Totally Enclosed Air Over
- Speeds: 1
- Protector: Thermally Protected
- Ambient Temp: 40°C
- Service Factor: 1
- Shaft Dimensions: 5/16″X2.30″
- Frequency: 60Hz
- Diameter: 3.3″
- Length: 4.58″
- Bearings: Ball
- Features: CLASS B INSUL., 36″ LEADS, 4X No. 10-24 UNC-2B THREAD 2.844BC, 12.5MFD 370VOLT CAPACITOR REQUIRED NOT SUPPLIED WITH MOTOR
- Weight: 6 lbs
- Cross References: Dayton 3M292, Fasco 7162-2516 7162-6118
