US Stove Company Coal Grate Fits Many Models (See Compatible Stoves). The grate is an essential part of your unit. It needs to be cleaned regularly. Overfiring can cause tremendous damage to the grate, affecting the function of your stove. Preventing overfire conditions can lengthen the life of the grate. If you see holes/cracks forming or notice warpage starting to occur the grate should be replaced!
Replacement For Part Number:
- 40101
Technical Specifications:
- Total Length- 24″
- Grate Length- 24 1/4″
- Width- 6 3/4″
Instructions:
1.) Make sure your unit has completely cooled.
2.) Open the cabinet door.
3.) Next, open the feed & ash pan doors.
4.) Reach in through the feed door and pull up on the grate.
5.) While pulling up on the grate, reach your other hand through the ash door opening and slide the grate out of position towards you (Pay attention to the orientation of the grate).
6.) To install the new grate, slide it into position through the ash pan door using one hand. At the same time reach in through the feed door opening with your opposite hand and position it back onto the grate supports.
7.) Close the ashpan door and feed door.
8.) The cabinet door can now be closed.
US Stove Company:
- Wondercoal 2627
- Wondercoal 2827
- Wondercoal 2927
- Wondercoal 3027
- Wondercoal 4027
- Wonderluxe 2607
- Wonderluxe B2350
- Wonderwood 2941
Vogelzang:
- VG9000 Hearth Deluxe
